Size:146X146、100X60mm、130X65、170X105mm
Maximum vacuum flow rate:140~650L/min
Introduction
- Handling without any contamination or influence on the subsequent product process
- Vacuum generator, suction cup and silencer integrated
- Suction cup’s contact side: PEEK material
- A detection sensor can be mounted to the main body
Application
- Applicable to handling fragile products such as photovoltaic cells, solar cells, glass
Structure
(1) Silencing tube
(2) Compressed air inlet
(3) Vacuum port
(4) Suction surface
3D Download
Catalog Download
MD-PEEK Composite Suction Cups Series Catalog
